دوربین مداربسته بوشNPC-20012-F2WL

Subtypes

NPC-20012-F2WL

TINYON IP 2000 WI

Basic Features

Resolution

Compact and stylish 720p

Image sensor type

۱/۴‑inch CMOS

Max. frames per second (fps)

۳۰

Indoor / outdoor

INDOOR

Day / night

 –

Built in ir

X

Wide Dynamic Range

۷۶ db

ONVIF conformant

√

Built-in microphone

microphone and loudspeaker

Power over Ethernet (PoE)

x

Advanced Features

Compression

H.264 (MP); M- JPEG

Multi-streaming

√

Intelligent Dynamic Noise Reduction

√

Intelligent streaming

√

Intelligent Auto Exposure

X

Remote commissioning

X

Privacy masking

√

Region Of Interest (ROI) & E-PTZ

X

Region Of Interest tracking

 X

No. of presets / guard tours

X

Wiper

X

Thermal

X

Alarm triggering

  √

Video analytics at the edge

X

Tamper detection

√

Video motion detection

√

Audio detection

 √

Face detection

  X

PTZ Intelligent Tracking

X

Sensitivity

Min. illumination day mode (color)

 ۱.۰ lx

Min. Illumination night mode (B/W)

۰.۰ lx

Starlight (extreme low-light)

 X

Integrated IR-lighting

Built-in PIR

Optional IR-lighting

X

Lens

Fixed 2.5 mm, F2.8

Automatic Back Focus (ABF)

 X

Varifocal

  X

Automatic Varifocal (AVF)

X

Iris control

 X

Focal length from

 –

Focal length till

 –

Horizontal Angle of View (HAoV)

۸۹° H & 50° V

Min. view angle (H)

–

Min. view angle (V)

–

Max. view angle (H)

–

Max. view angle (V)

–

DCRI distances (in m with 100 lux illumination)

Detection

–

Classification

–

Recognition

–

Identification

–

Storage

(micro)SD card slot

x

Direct-to-iSCSI

√

Cloud storage

  √

Connections

Alarm input / output

Alarm input

Audio in/out

Built-in microphone/Built-in loudspeaker

Hybrid

 x

Confrontation monitor

√

۱۲VDC power output

+۵ VDC via supplied power adapter

Housing

Weather rating

–

Vandal resistant

–

Corrosion resistant

 X

Operating temperature

-۱۰ ºC to +40 ºC
