The VULCAN 2 C is a low consumption sounder designed to be used as an unobtrusive low profile sounder or as a base sounder to be installed in conjunction with a conventional detector. This results in reduced installation costs and improves the aesthetics of the fire alarm system. Four different tones are available and selected by jumpers . The sound level can be adjusted using the potentiometer if required.
The complete range is composed of three varieties in both base and wall mounted versions: beacon, sounder and combined sounder/beacon.
|SUPPLY VOLTAGE||20 V to 30 V DC|
|LOOP CURRENT – BEACON||2.5 mA|
|MAXIMUM SOUNDER OUTPUT||96 dB (@ 1 m – 30 V DC)|
|MAX. CABLE SIZE||2.5 mm²|
|OPERATING TEMPERATURE||-10ºC to 55ºC|
|MAX. HUMIDITY||95% RH Non-Condensing|
|CASE MATERIAL||ABS and Transparent PC|
|COLOUR||Red or White|
|DIMENSIONS||100 (D) x 29 (H) mm|
|WEIGHT||144 g inc. Lid|
