اینترفیس RS232-RS485 Converter

دسته بندی: سیستم اعلام حریق / اینترفیس اعلام حریق / اینترفیس گلوبال فایر Panel-to-PC
رنگ:
سایز:
وضعیت: تماس بگیرید
تومان
تومان تومان
توضیحات

This converter translates RS485 voltage levels to RS232 enabling the connection of GFE addressable panels to a PC with our ODYSSEY software installed. The power to this converter comes directly from the PC.



SUPPLY VOLTAGE 12 V DC nominal – Does not require external supply
CURRENT CONSUMPTION 3 mA + transmission load current
COMMUNICATIONS SETTINGS Half Duplex – 4 wire
9600 baud – 8 data bits – 1 stop bit – no parity
PROTECTION CATEGORY IP44
CONNECTOR TYPE RS232 side DB9 Female – RS485 side DB9 Female
MAX. HUMIDITY 95% RH Non-Condensing
OPERATING TEMPERATURE -10ºC to 50ºC
DIMENSIONS 78 (L) x 43 (W) x 20 (H) mm
WEIGHT 40 g
