دوربین مداربسته بوش NBN-50022-V3
توضیحات
Subtypes |
|
NBN-50022-V3 |
DINION IP 5000 HD |
Basic Features |
|
Resolution |
۲MP |
Image sensor type |
۱/۲.۷‑inch CMOS |
Max. frames per second (fps) |
|
Indoor / outdoor |
Indoor/Outdoor(WITH HOUSING) |
Day / night |
Day/Night |
Built in ir |
X |
Wide Dynamic Range |
۷۶db |
ONVIF conformant |
√ |
Built-in microphone |
√ |
Power over Ethernet (PoE) |
√ |
Advanced Features |
|
Compression |
H.264 (MP); M- JPEG |
Multi-streaming |
√ |
Intelligent Dynamic Noise Reduction |
√ |
Intelligent streaming |
√ |
Intelligent Auto Exposure |
X |
Remote commissioning |
X |
Privacy masking |
√ |
Region Of Interest (ROI) & E-PTZ |
√ROI& E-PTZ |
Region Of Interest tracking |
√ |
No. of presets / guard tours |
X |
Wiper |
X |
Thermal |
X |
Alarm triggering |
√ |
Video analytics at the edge |
X |
Tamper detection |
√ |
Video motion detection |
√ |
Audio detection |
√ |
Face detection |
X |
PTZ Intelligent Tracking |
X |
Sensitivity |
|
Min. illumination day mode (color) |
۰.۲۵ lux |
Min. Illumination night mode (B/W) |
۰.۰۵ lux |
Starlight (extreme low-light) |
X |
Integrated IR-lighting |
X |
Optional IR-lighting |
X |
Lens |
|
Automatic Back Focus (ABF) |
X |
Varifocal |
√ |
Automatic Varifocal (AVF) |
X |
Iris control |
Automatic iris control |
Focal length from |
۳.۳ MM |
Focal length till |
۱۲ MM |
Horizontal Angle of View (HAoV) |
۳۴° – ۱۱۰° |
Min. view angle (H) |
۳۴° |
Min. view angle (V) |
۱۸º |
Max. view angle (H) |
۱۱۰° |
Max. view angle (V) |
۵۸º |
DCRI distances (in m with 100 lux illumination) |
|
Detection |
۲۷-۱۲۵ m |
Classification |
۱۱-۵۰ m |
Recognition |
۵-۲۵ m |
Identification |
۳-۱۳ m |
Storage |
|
(micro)SD card slot |
√ |
Direct-to-iSCSI |
√ |
Cloud storage |
√ |
Connections |
|
Alarm input / output |
√ |
Audio in/out |
√ |
Hybrid |
√ |
Confrontation monitor |
√ |
۱۲VDC power output |
PoE and +12 VDC |
Housing |
|
Weather rating |
X |
Vandal resistant |
X |
Corrosion resistant |
X |
Operating temperature |
-۳۰° to 50° C |
جهت دریافت مشاوره فنی و بهترین قیمت دوربین مداربسته بوش BOSCH فروشگاه آموت در خدمت شماست .
